Lub npe: Ncua tseg clamp
Hom: Kub dip galvanized ncua kev kawm ntawv clamp
Yam khoom: Aluminium alloy ncua kev kawm ntawv clamp
Mechanical load Range: 40kN -82kN
Txuj: ASTM A -153, BS729
Khoom siv: Aluminium alloy, Kub dip galvanized steel
Daim ntawv thov: Overhead kab hluav taws xob system
Ncua tseg clamp yog tsim los muab cov conductors ob lub cev thiab txhua yam kev txhawb nqa. Qhov no yog qhov tseem ceeb tshwj xeeb tshaj yog thaum koj tau teeb tsa cov conductors rau cov kab hluav taws xob xa hluav taws xob thiab cov xov tooj.
Ncua tseg clamps txhim khu kev ruaj ntseg ntawm tus neeg xyuas pib los ntawm kev txwv lawv cov kev txav tshwj xeeb tshaj yog tiv thaiv cua, cua daj cua dub, thiab lwm yam vagaries ntawm xwm. Lawv muaj lub zog tensional txaus los txhawb qhov hnyav ntawm cov neeg xyuas pib mus rau txoj haujlwm zoo meej.
Ncua tseg clamps feature ib tug ntse ergonomic tsim uas ua kom ntseeg tau tias qhov hnyav ntawm tus neeg xyuas pib sib npaug ntawm lub clamp lub cev. Qhov kev tsim no kuj muab cov ces kaum zoo meej ntawm kev sib txuas rau tus neeg xyuas pib. Qee zaum, counterweights raug ntxiv los tiv thaiv tus neeg xyuas pib qhov kev txhawb nqa. Lwm yam fittings xws li txiv ntseej thiab bolts yog siv nrog rau cov ncua kev kawm ntawv clamps los txhim kho kev sib txuas nrog cov conductors.
Ncua tseg clamp lub ntsiab parameter:
Hom | Siv tau conductor txoj kab uas hla | Qhov Loj (mm) | Rated tsis load | Kwv yees qhov hnyav | ||||
mm | H | C | M | R | L | kN kev | kg | |
CGH-2 | 5.1-12.5 | 55 | 17 | 16 | 7 | 170 | 40 | 0.71 |
CGH-3 | 12.4-18.5 | 62 | 22 | 16 | 10.5 | 180 | 50 | 1.1 |
CGH-4 | 17.8-26.0 | 62 | 27 | 16 | 13.0 | 203 | 50 | 1.55 |
CGH-5 | 25.0-35.0 | 68 | 37 | 16 | 18.0 | 216 | 70 | 2.00 |
CGH-6 | 25.0-35.0 | 68 | 37 | 16 | 18.0 | 216 | 70 | 2.00 |
CGH-7 | 30.0-42.5 | 85 | 47 | 16 | 23.0 | 245 | 82 | 2.15 |
Peb Cov Kev Pabcuam:
1. Kev paub nplua nuj hauv ODM thiab OEM
2. Zoo heev One-stop service
3. High Quality Precision Customized forging & Casting kev pab cuam
4. Tus nqi qis tshaj
5. Kev tswj xyuas nruj
6. Peb tuaj yeem tsim nws raws li cov neeg siv khoom xav tau.
FAQ:
Q: Kuv puas tuaj yeem tau txais qee qhov qauv?
A: Yog lawm, qauv txiav txim yog muaj rau kev kuaj xyuas zoo thiab kev ua lag luam.
Q: Koj cov nqe lus them nqi yog dab tsi?
A: Peb feem ntau lees txais txhua yam kev them nqi, T / T, L / C, Nyiaj Ntsuab.
Q: Koj tuaj yeem tswj koj qhov zoo li cas?
A: Rau txhua qhov kev tsim khoom, peb tau ua tiav QC system rau cov tshuaj muaj pes tsawg leeg, lub cev thiab hluav taws xob. Tom qab kev tsim khoom, tag nrho cov khoom yuav raug kuaj raws li cov qauv muaj feem xyuam, thiab cov ntawv tshaj tawm ntawm lub Hoobkas yuav raug xa nrog rau cov ntaub ntawv xa khoom.
Q: Koj lub tuam txhab puas txais customization?
A: Peb txais kev pabcuam OEM.
Q: Koj puas muab cov qauv? Puas yog dawb?
A: Yog tias tus qauv qis qis, peb yuav muab cov qauv dawb nrog cov khoom thauj. Tab sis rau qee qhov kev kuaj tus nqi siab, peb yuav tsum tau sau tus nqi coj mus kuaj, tus nqi coj mus kuaj tuaj yeem xa rov qab rau cov neeg siv khoom yog tias lawv tso qhov kev txiav txim.
Q: Koj lub sijhawm them nyiaj yog dab tsi?
A: T / T lossis 100% LC thaum pom.
Cim npe nrov: ncua clamp
