Lub npe: ceramic ncej insulator
Hom: 57-3 ceramic ncej insulator
Yam muaj feem xyuam: 57-2, 57-4, 57-5
Voltage Ntau: 11kV ~ 33kV
Txuj: IEC60383, ANSI C29.7
Graze xim ntawm insulators: xim av los yog grey
Mechanical tsis load: 8kN, 12.5kN
Khoom siv: Alumina thiab silica porcelain
Daim Ntawv Thov: Cov kab hluav taws xob siv hluav taws xob thiab cov kab sib kis

Ceramic ncej insulator yog khi rau sab saum toj, cov pob txha thiab hlau hau rau cov ncej insulator yuav tsum tau kub-dip galvanized raws li cov qauv kev lag luam tsim nyog thiab ua tiav nrog cov txiv ntseej thiab ntxhua khaub ncaws rau steel crossarm mounting. Cov qauv kuaj raws li qhov cuam tshuam rau IEC lossis sib npaug ANSI cov qauv yuav tsum tau ua ua ntej lub Hoobkas xa khoom.

Technical specifications:

Cov khoom siv insulator	Porcelain	Porcelain
Hom	Kab Post Insulator	Kab Post Insulator
Siv tus lej qauv	IEC 60383.1, ANSI C29.7	IEC 60383.1, ANSI C29.7
Kev pabcuam	Sab nraum zoov	Sab nraum zoov
Nominal Voltage (kV)	33	33
Qhov siab (mm)	368	368
Zuag qhia tag nrho txoj kab uas hla (mm)	165	178
Creepage nrug (mm)	737	825
Cantilever zog (kN)	12.5	12.5
Tsawg zaus ntub flashover voltage (kV)	95	100
Critical impulse pos flashover voltage (kV)	200	210
Ua kom tiav nrog studs	Luv stud	Luv stud
Xim ntawm porcelain	Brown glazed	Brown glazed

Peb Cov Kev Pabcuam:

1. Kev paub nplua nuj hauv ODM thiab OEM
2. Zoo heev One-stop service
3. High Quality Precision Customized forging & Casting kev pab cuam
4. Tus nqi qis tshaj
5. Kev tswj xyuas nruj
6. Peb tuaj yeem tsim nws raws li cov neeg siv khoom xav tau.

FAQ:

1.Q: Koj cov khoom tseem ceeb yog dab tsi?
A: porcelain thiab composite insulators, kho vajtse ntawm txhua yam rau high-voltage daim ntaub ntawv thiab lwm yam khoom.

2.Q: Koj qhov kev pabcuam shipping yog dab tsi?
A: Peb tuaj yeem muab cov kev pabcuam rau kev booking nkoj, khoom sib sau ua ke, kev tshaj tawm kev lis kev cai, kev npaj cov ntaub ntawv thauj khoom thiab xa khoom ntau ntawm qhov chaw nres nkoj shipping.

3.Q: Koj tus MOQ yog dab tsi?
A: Feem ntau, MOQ yog 100pcs, Yog tias peb muaj cov khoom hauv Tshuag, nws yuav tsis muaj MOQ. Yog tias peb xav tau tsim, peb tuaj yeem tham txog MOQ raws li tus neeg siv khoom qhov xwm txheej

4.Q: Thaum twg kuv tuaj yeem tau txais tus nqi?
A: Feem ntau peb hais hauv 24 teev tom qab peb tau txais koj qhov kev nug.

5.Q: Koj puas kuaj tag nrho koj cov khoom ua ntej xa khoom?
A: Yog lawm, peb muaj kev sim ua ntej xa khoom.

6.Q: Koj puas tuaj yeem muab Daim Ntawv Qhia E, C / O lossis 3rd Party Test?
A: Yog, peb tuaj yeem muab tau, peb kuj tuaj yeem thov lub embassy stamp rau koj yog tias tsim nyog.
